Product Details

Description

🧾 Key Features
- Printing Technology: Thermal line printing
- Print Speed: Up to 200 mm/sec
- Paper Width: 80 mm or 58 mm (with spacer)
- Resolution: 203 dpi
- Auto Cutter: Rated for 1.5 million cuts
- Reliability:
- MCBF: 60 million lines
- MTBF: 360,000 hours
- Connectivity Options: USB, Serial, Ethernet, or Bluetooth (model dependent)
- Dimensions: 140 x 199 x 146 mm (W x D x H)
- Weight: Approx. 1.7 kg
- Energy Efficiency: ENERGY STAR® qualified
- OS Compatibility: Windows, iOS, Android, Linux, macOS

📦 In the Box
- TM-T20II printer
- Power adapter & cable
- USB or serial cable (depending on model)
- Sample paper roll
- Setup guide & driver CD
- Wall-mount bracket & rubber feet

Specifications

🖨️ Printing
- Method: Thermal line printing
- Speed: Up to 200 mm/sec
- Resolution: 203 dpi
- Character Set:
- 95 Alphanumeric
- 18 International sets
- 128 × 43 Graphic
- Fonts: 9×17 and 12×24 dots/character
- Character Size: 0.88 × 2.13 mm and 1.25 × 3 mm
- Barcodes Supported: UPC-A/E, EAN13/8, CODE39, ITF, CODABAR, CODE93/128, GS1
- 2D Codes: PDF417, QR Code, MaxiCode, GS1 DataBar

📄 Media Handling
- Paper Width: 80 mm or 58 mm (with spacer)
- Roll Diameter: Max 83 mm
- Auto Cutter: Rated for 1.5 million cuts

🔌 Connectivity
- Interfaces (varies by model):
- USB
- Serial
- Ethernet
- Bluetooth
- DKD Function: 2 drivers (for cash drawer control)

⚙️ Reliability
- MCBF: 60 million lines
- MTBF: 360,000 hours
- Print Head Life: 15 million lines

📐 Physical
- Dimensions: 140 × 199 × 146 mm (W × D × H)
- Weight: Approx. 1.7 kg
- Color Options: Epson Dark Grey or White

🔋 Power
- Supply: 100–240V AC, 50/60 Hz
- Consumption: ENERGY STAR® qualifie
